When an analysed and market strategized idea meets a capable workmanship, then a product is born. With our current experience and knowledge, we are capable to give solutions to our clients for following technicalities:

Microcontroller Functionality

  • To enhance the system processing with limited space and cost, embedding microcontrollers is always a better choice.
  • We are enough experienced in coding for STM8S series, PIC, Atmel and 8051 controllers.
  • We can code them for following processes:
  • Minimal or large input/output requirement.
  • UART communication interfacing.
  • Interrupt driven critical processes.
  • Timer based precise delays and variable pulse generation.
  • Accurate ADC measurement for converting various physical, electrical and thermal quantities to digital form.
  • PWM techniques used in motor speed control, stepper and servo motor control.
  • Also, with controllers we can actuate relays or contactors on trigger signals, raise alarms, PIR sensing, keypad input, etc functionalities.
  • We still have a learning approach towards the new design concepts, techniques we come across and are looking forward to our customer’s needs.

Custom PCB Designing

  • For a miniature design product with many functionalities a compact and crisp PCB is essential.
  • We can design PCB with following specifications:
  • Both single and double layered as per need.
  • Of any required package size of components like SMD (Surface Mount Device), through hole, DIP (Dual In-Line Package), QFP (Quad Flat Package), TSSOP (Thin Shrink Small Outline Package) and SOIC (Small Outline Integrated Circuit).
  • For both control as well as power circuitry with enough isolation using board cut-outs.
  • Use copper-pour techniques including hatched and solid copper pour for reducing ground impedance, pressure drop and improve power efficiency and anti-interference ability.
  • Testing the designed PCB for required functionality of the electronic circuit embedded.
  • We can also provide SMT/SMD stencil for your PCB if needed for mass production.
  • Apart from designing, we can also handle PCB’s manufacturing and component assembling using our third parties.
  • We still have a learning approach towards the new design concepts, techniques we come across and are looking forward to our customer’s needs.

Embedding Digital Display

  • For any system requiring a good user interface, a display for outputting the result is necessary.
  • We can embed display with 0.28”, 0.36” and 0.56” SSD and 16 x 2 LCD with as much characters required.
  • These displays are perfect for displaying voltage, current, temperature, tap position, counts, delay time, etc. We mainly focus on electric panel instruments for display.

Enclosure Design

  • For any electronic product an enclosure is mandatory for easy and safe use of the product by customer.
  • Using latest CAD techniques, we can design a customer proposed enclosure.
  • Along with designing we offer facility of a testing enclosure which can be 3D printed at our premises for testing purpose.
